ORC-Based Geothermal Power Generation and CO2-Based EGS for Combined Green Power Generation and CO2 309 Sequestration http://dx.doi.org/10.5772/52063 C o o l i n g Tower Surface Figure 2. A schematic diagram showing the basic concept of a low-temperature geothermal binary ORC system for electrical power generation. pump to be re-evaporated, and the power cycle repeats itself. One of the most important performance criteria in low-temperature geothermal ORC power generation technology re‐ quires the optimal selection of the ORC organic working fluid. Organic fluids used in binary ORC technology have inherent feature (compared to water) and that is they have low boil‐ ing temperature and high vapor pressure at relatively low temperatures, compared with steam (water) (Dickson & Fanelli, 2005). Typical ORC organic fluids may include pure hydrocarbons (e.g. pentane, butane, propane, etc), refrigerants (e.g. R134a, R218, R123, R113, R125, etc), or organic mixtures (Panea et al., 2010; Saleh et al., 2007; Hung, 2001; Wei et al., 2007). The optimal energy conversion per‐ formance of a low-temperature geothermal ORC power generation system depends mainly on the type of organic fluid being used in the system (Ismail, 2011a). The selection of the type of organic fluid is normally based on the following criteria (Hettiarachchi et al.,2007; Saleh et al., 2007; Chandrasekharam& Bundschuh, 2008; Ismail, 2011b): Electric Generator T u r b i n e ORC BINARY POWER CYCLE Heat Exchanger (Evaporator) Production well Electric Power Output Condensate Pump Condenser bsurface Re-injection well S Sub Low-temperature geothermal liquid-dominated resourcePDF Image | ORC-Based Geothermal Power Generation and CO2- Based EGS for Combined Green Power Generation and CO2 Sequestration
