site preparations, permitting and interconnects, and profits. O&M calculations are determined based on inverter lifetimes and as an annual percentage of overall installed system cost, based on benchmarking data available. In all of the reference applications below, the greatest reductions in LCOE come through module improvements in performance and cost, and through modifications to the system-level component integration, thereby reducing installation and O&M costs and increasing overall reliability. This increase in systems integration is reflected in the relatively stable contribution of “other costs” to the system LCOEs over time. Although several components of this “other” category are reduced over time, the system engineering costs are increased, resulting in significant reductions in BOS, installation, and O&M contributions to LCOE. The types of activities to achieve these targets are defined in Sec. 3.1.8. Table 3.1.6-2 2005 Benchmarked Parameters, 2011 and 2020 Projections for Modeling of 4-kW Residential Reference System 2005 benchmark cost and performance values contained here are from detailed data on more than 200 residential PV systems installed between 2000 and 2005, with emphasis on those more recently installed; Web-based price information on more than 5000 installations in 2004 and 2005; and laboratory-based measurements and modeling. Out-year projections are based on the PV industry roadmap, earlier versions of this Multi-Year Plan, and input from engineers and scientists in the DOE Solar Program and in industry. 42PDF Image | Solar Energy Technologies Program
