132 The Energy Evolution With appropriate minor structural alterations the implosion-machine (suction-turbine) can be used for a variety of purposes.8 1. For the generation of free energy in any quantity, whereby the water used to fill it is converted into noble water. 2. As a generator for the achievement of manifold increase in growth. If embedded in the ground, the energetically charged water radiates growth-enhancing forces down into the earth. 3. For obtaining individually constituted noble waters, which charge up the body cells, dissolve deposits and reduce inflammation. 4. For the propulsion of aircraft, which can never malfunction and crash. The great difficulty thus far was the manufacture of the whorl-pipes them- selves and the dynamic balancing of the rotor for the necessarily high rate of rotation. The machine consists of a cylindrical pipe (see figs. 20 & 21), whose diameter and wall strength must be suited to the desired performance. The bottom plate, which also has a stable base fitted, is welded or riveted onto the cylinder. The plate carrying the motor, the dynamo and the whorl-pipe rotor is fixed to the top end of the cylinder with angle brackets. All three components rotate on a single, common axle. Because the carrying plate is mounted on rubber vibration pads, the axle takes up all the vibration and permits both high and highest rotational speeds. The rotor itself is hollow and houses the real heart of the machine. In the upper part of this hollow body a hub is attached from which the whorl-pipes project. This hub is an enclosed hollow form. It is attached to the rotor and turns with it. On its underside there is a opening for the intake of the suction-pipe. It extends deep into the lower part of the machine where the drive-water is present. The whorl-pipes are conical and various types of jet-nozzles can be fitted to the ends (see figs. 29a & 29b) The tips of these nozzles are turned towards the direction of rotation. Opposite the exit openings and attached to the periphery of the cylinder, a harmonica-like sheet-metal band is attached. It is against this that the water jets are impelled at a wide angle. The rotor is then forced to move in the direction of rotation through the resulting recoil and is thus set in rotation. As soon as the motor has set the generator and rotor in motion, the air or water will be sucked up the suction or rising pipe and into the rotor hub and centrifugated down the whorl-pipes. A vacuum is thereby created, which lifts the drive-water like any pump. The centrifugally impelled water, on impact with the sidewalls, would begin to flow in a circular path and all the water would remain at the outer wall. To prevent this, radial baffles must be installed to calm the water and conduct it back to the suction-pipe. 8 Either as a Repulsator or a Repulsine. — Ed.PDF Image | The Energy Evolution
