PDF Publication Title:
Text from PDF Page: 033
Exhibit 6: Waste Streams, Industries of Origin, and Characteristic Temperatures Coded by Color Waste Heat Source 1) The Exhaust gases or vapors a) High temperature combustion products - clean. b) High-temperature flue gases or combustion products with contaminants. c) Heated air or flue gases containing high (>14%) O2 without large amount of moisture and particulates. d) Process gases or by-product gases and vapors that contain combustibles. e) Process or make-up air mixed with combustion products, large amounts of water vapor or moisture. f) Steam discharged as vented steam or steam leaks. g) Other gaseous streams. 2) Heated water or liquids a) Clean heated water discharged from indirect cooling systems. Steel Aluminum Glass Paper Pet. Refining Mining Chemical Food Cement Coating Steam generation b) Hot water that contains presence of large amount of seperatable solids. c) Hot water or liquids containing dissolved precipitatable solids or dissolved gases. 3) Hot products a) Hot solids that are air cooled after processing. b) Hot solids that are cooled after processing using water or air-water mixture. c) Hot liquids and vapors that are cooled after thermal processing. 4) High temperature surfaces a) Furnace or heater walls. b) Extended surfaces or parts used in furnaces or heaters. Temperature Color Code Key Ultra High temperature (>1,600oF) High temperature – between 1,200oF and 1,6000F Medium temperature – between 450oF and 1,200oF Low temperature – between 250oF and 450oF Ultra low temperature – below 250oF Industrial Waste Heat Recovery Page 23PDF Image | Industrial Waste Heat Recovery: Potential
PDF Search Title:
Industrial Waste Heat Recovery: PotentialOriginal File Name Searched:
