Sustainability 2019, 11, 1881 12 of 20 Figure 9. Properties of system configurations desirable at 30 ◦C ambient temperature and 50% water recovery yield: (a) map of configurations A, B, and X based on outlet temperature and number of stages; (b) map of configurations A, B, and X based on water recovery efficiency along with the number of stages; and (c) map of the power output of configurations A, B, and X with respect to the number of stages. 3.1.3. At 20 ◦C Ambient Temperature Figure 10a–c shows that configuration A is the only candidate selected from all five configurations that can achieve the desired water recovery efficiency at a flue gas outlet temperature of 40 ◦C at the highest power output with the least number of stages. Figure 10. Properties of the system configurations for a 20 ◦C ambient temperature and 50% water recovery yield: (a) map of configuration A based on its outlet temperature and the number of stages. (b) Map of configuration A based on its water recovery efficiency along with the number of stages. (c) Map of configuration A power output with respect to the number of stages.PDF Image | Waste Heat and Water Recovery System Optimization for Flue Gas
