129 a b c Figure 5-7 presents the effect of loading coefficient 𝛹 on the same parameters mentioned in the previous paragraph. Figure 5-7aand Figure 5-7b show that the effect of 𝛹 has a slight significanceon 𝜂𝑡𝑠 and is insignificant on 𝑊𝑜𝑢𝑡 . However, the results in Figure 5-7agree well with [231], in which the turbine shows better performance with 𝛹 falling in the range of 0.8–1. Furthermore, loading coefficient 𝛹 has a significant effect on the turbine size and Mach number, as shown in Figure 5-7cand Figure 5-7d, respectively. This phenomenon is directly related to the definition of the loading coefficient 𝛹 in equation (4-7), where the increase of 𝛹 leads to higher enthalpy drop and,therefore, a smaller diameter. The decrease of 𝑈4 results in higher absolute velocity at the rotor inlet 𝐶4, thereby leading to the higher Mach number 𝑀4(Figure 5-7d). Figure 5-6: Effect of flow coefficient 𝜑 on the investigated parameters. dPDF Image | Automotive Radial Turbine Expander Design WHR
