Text from PDF Page: 017

Modeling and Analysis for WGS in Zeolite Tubule Membrane Reactor (Task 3.0) β€’ CO+H2O=H2 +CO2 β€’ H2 permeation: Shell (reaction) side β†’ Tube side β€’ Counter-current mode Catalysts Conversion: 𝑋𝐢𝑂 = 𝐹𝐢𝑂, π‘“π‘’π‘’π‘‘βˆ’πΉπΆπ‘‚, π‘Ÿπ‘’π‘‘π‘’π‘›βˆ’πΉπΆπ‘‚, π‘π‘’π‘Ÿπ‘š 𝐹𝐢𝑂, 𝑓𝑒𝑒𝑑 Purity: 𝐺𝐻2 = 𝐹𝐻2, π‘π‘’π‘Ÿπ‘š πΉπ‘‘π‘œπ‘‘π‘Žπ‘™, π‘π‘’π‘Ÿπ‘š Recovery:𝑅𝐻2 = 𝐹𝐻2,π‘π‘’π‘Ÿπ‘š 𝐹𝐻2, π‘Ÿπ‘’π‘‘π‘’π‘›+𝐹𝐻2, π‘π‘’π‘Ÿπ‘š , 𝐺𝐢𝑂2 = 𝐹𝐢𝑂2, π‘Ÿπ‘’π‘‘π‘’π‘› πΉπ‘‘π‘œπ‘‘π‘Žπ‘™, π‘Ÿπ‘’π‘‘π‘’π‘› Capture:𝑅𝐢𝑂2 = 𝐹𝐢𝑂2,π‘Ÿπ‘’π‘‘π‘’π‘› 𝐹𝐢𝑂2, π‘Ÿπ‘’π‘‘π‘’π‘›+𝐹𝐢𝑂2, π‘π‘’π‘Ÿπ‘š 17

PDF Image | Zeolite Membrane Reactor CO2 Capture

zeolite-membrane-reactor-co2-capture-017
